Sunday, 07 September 2008 |
Universal Docking System for Tester to Handlers and Probers | P-Dock® System - Smallest Footprint
- Easy Operation
- Accurate Adjustment
- Pre-Lock Adjustment
- Smart Guiding concept
- Fastest setup on all Tester
- Easiest Z-Stack Adjustment
- Available on all Tester Platform
- Compatible to all OEM Docking
- Best Repeatability
|
| Specification :
The P-Dock® system provides high flexibility on the testfloors having can one solution for all tester, handler and wafer prober integration. P-Dock® get mounted on tester, prober or handler side. the system is iptionally offered with a Z-axis adjustment between 20 mm and 50 mm, having an accuracy of 0,1 mm. | Technical Data :Dimension : Diameter 112mm
Height 31.5mm
Weight : 0.65kg per module
Required : Compressed Air
Docking Force : 200 - 2000 N per module | | Universal Docking Plate The universal docking plate XL is suitable for most testers, probers and handlers available on the market.
The plate offers a central Z-axis adjustment of 40 mm with an accuracy of 0,1 mm | | Technical Data :Dimension : Length 110mm
Width 1000mm
Height 15mm
Weight : 28 Kg
Z-Stack : 40mm in steps of 0.01mm
Accuracy : 0.1mm | |
|
|
Last Updated ( Monday, 29 September 2008 )
|
|
Read more...
|
|
|
Sunday, 07 September 2008 |
P-Lift ® SystemThe P-Lift ® system is a pneumatic lift device to move up"Pick and Place" handlers without any further tools needed. The P-Lift ® system gives "Pick and Place" handlers more flexiblity to move around. The system can be integrated into existing machines, making maintenance easier than ever before. | | - Easy Operation
- No tools required
- Fast setup time
- Stability
- Adjustable like hinged foot
- No Software required
| | Technical Data Axial movement : 30mm
Dimension : Diameter 145mm x Height 150mm
Required Media : Compressed Air
Axial Force : 7000N at 6 bar (80 psi) per module
Air Storage : More than 8 Hours. | |
|
|
Last Updated ( Monday, 29 September 2008 )
|
|
|
Monday, 08 September 2008 |
eZTac CoatingA new innovative high electronic, non-chemical and environmentally safe process to ehnance the surface of contactor fingers, lead frames and pins. Only areas that are subjected to abrasion are coated and teh parts will retain its overall dimension and characteristics. It will increase the life span of the coated parts and at the same time prevent contamination of the pins from solder migration. It is a solution for lead free devices testing. |
|
- Increase Pin life span
- Reduce contaminations
- Selective area coating
- Better first pass yield
- Consistent Test Yield
- Reduce downtime
- Lower cost of Test
| |
Coating also available in non-conductive type for extending life span and with anti contamination properties of polymer parts. |  | | Contact :
